Mirror systems for small and large municipal vehicles
Mirror systems for municipal vehicles should be as small as possible while providing as large a field of vision as possible. MEKRA Lang mirror systems 1009 (for larger vehicles) and 1010 (for smaller vehicles) meet these requirements. With our intelligent flexible attachment options, we can provide the right solution for any municipal vehicle.
Your MEKRA sales representative will be happy to show you the whole range of possibilities, from manually and electrically adjustable heated mirrors to our camera monitor system portfolio.
Mirror systems
COMPACT MIRROR 1010
| Glass-Size |
169 x 277 mm (W x H) |
| Curvature Radius |
1200 mm |
| Mounting-Side |
right and left side |
| Heating |
unheated or heated 12 V |
| Adjustment |
manual |
| Adjustment-Range |
up / down: > ±9° - left / right: > ±9° |
| Mounting-Interface |
Clamp for 14-20 or 28-22 mm tube diameter |
| On-Board Power Supply Connection |
- |
| Material |
shock-proof ASA plastic, black, UV resistant |
MODULAR MIRROR 1009
| Glass-Size |
Main mirror 225 x 286 mm (W x H)
|
| Curvature Radius |
Main mirror 1200 mm
|
| Mounting-Side |
right and left side |
| Heating |
unheated or heated 12 or 24 V |
| Adjustment |
manual or electrical 1 or 24 V |
| Adjustment-Range |
up / down: > ±8° - left / right: > ±8° |
| Mounting-Interface |
Clamp for 18-22 or 28 mm tube diameter |
| On-Board Power Supply Connection |
2- or 6-lead flange socket,
|
| Material |
shock-proof ASA plastic, black, UV resistant |
Mounting system
MIRROR MOUNTING SYSTEM 1016
| Pipe-Diameter |
22 mm |
| Mounting-Side |
links |
| Material |
Stahlrohr, pulverbeschichtet, schwarz |
| Maße |
336 x 136 x 0 mm |
| Brottogewicht |
1,06 Kg |
You will find a distributor near you in our extensive network of authorized dealers:
